Product Details
＋
| Product Attribute | Attribute Value |
|---|---|
| Alternate Mfr Part Number | SFP 1-15/120AC |
| Approvals | CSA, cCSAus |
| Clamping Voltage | ≤400 V |
| Current, Surge | 3 kA |
| Dimensions | 93mm L x 112mm W x 79mm H |
| For Use With | Industrial Equipment |
| IP Rating | IP20 |
| Mounting Type | DIN Rail Mount |
| Product Header | Device Surge Protection Filter |
| Series | |
| Supply Voltage | 120 VAC |
| Termination | Screw |
| UPC Code | 4046356158565 |
| Voltage, Operating | 250VAC ; 300VDC |
| Wire Size | 28-16 AWG |
Overview
This product provides both EMI/RFI filtering and transient voltage surge suppression in one industrial DIN-rail mount package. Best used in applications where tight clamping and high surge current capabilities are required.
